VertX访问控制器

VertX® Access Controllers The HID VertX products provide a complete and fully featured hardware/firmware infrastructure for communicating via industry standard TCP/IP protocol.VertX is an open architecture access control panel that enables HID’s softwarepartners to deploy a wide variety of access control solutions. Unlike proprietaryaccess control solutions, VertX provides the customer the ability to install newsoftware head ends over time while keeping the panel in place, therefore avoidinginstallation and other costs associated with panel hardware changes. V1000 - Networked Controller Genuine HIDValue V1000 Access Controller Base Part Number • 71000ƒ Communicates directly with OEM access control software hostsystemsƒProvides on-board processing and memory to support up to 32downstream interface panelsƒController has two independent RS485 networks, each having twosets of input connection for optimum system topologyƒAllows local connection of a laptop computer for diagnostics andconfigurationƒReports supervised inputs/alarms with 255 prioritiesƒPower supply 12-18 VDC @ 210 mA QualityƒDeveloped, tested and manufactured in ISO-certified facilities.ƒFrom market leader HID,the world’s most trustedbrand for high qualityaccess control cards andreaders. V100 - Door/Reader Interface The V100 connects two access control card readers byWiegand. Base Part Number • 70100ƒ Connects to the V1000 via a high speed RS485 networkƒConnects 2 access control card readers via Wiegand orClock-and-Data interface controlling 1 or 2 doorsƒProcesses off-line access control decisions based on facility codeƒFlash memory for downloading program updatesƒPower supply 9-18 VDC @ 100 mA Partnership ƒDeveloped in collaborationwith software leaders inaccess control and securityaround the globe.ƒOPIN® API softwaredevelopment platformenables robust andextensive access control. V200 - Input Monitor Interface Service Base Part Number • 70200ƒ Connects to the V1000 via a high speed RS485 networkƒAlarm input processing for up to 16 supervised input circuitsƒMonitors & reports normal, Off/Normal & tamper statusƒFlash memory for downloading program updatesƒPower supply 9-18 VDC @ 100 mA ƒDedicated applicationengineering and technicalsupport staff.ƒIntegrator trainingsupported through HIDAcademy, both live andonline atwww.hidtraining.com. ValueƒAffordable purchase price. V300 - Output Control Interface ƒEasy to buy, sell andmaintain through OEMsoftware providersƒVariety of softwareproviders allows for a wideselection of solutionsƒAbility to switch softwaresolutions while maintaininghardware providesprotection of hardwareinvestmentƒGenerates opportunity forincremental services toexisting customers. The V300 controls up to 12 outputs. Base Part Number • 70300 ƒConnects to the V1000 via a high speed RS485 networkƒOutput control processing for up to 12 devicesƒContains 12 latching Form C relays connecting up to 12 devicescontrollable by simple contact closuresƒOff/Normal status programmable for each input pointƒFlash memory for downloading program updatesƒPower supply 9-18 VDC @ 100 mA V2000 - Access Controller/ReaderInterface The V2000 Reader Interface/Access Controller is acombination of a V1000 and a V100. Base Part Number • 72000 ƒComplete two door/reader unit for installations using TCP/IPcommunications to the central stationƒNo End User Software Installation NecessaryƒV2000 communicates by TCP/IP onlyƒIdeal for small installationsƒPower supply 12-18 VDC @ 210 mA An ASSA ABLOY Group brand © 2011 HID Global. All rights reserved. HID, the HID logo,Crescendo, naviGO, OMNIKEY, HID on the Desktop, andHID Identity on Demand are trademarks or registeredtrademarks of HID Global in the U.S. and/or othercountries. All other trademarks, service marks, andproduct or service names are trademarks or registeredtrademarks of their respective owners. North America: +1 949 732 2000 • Toll Free: 1 800 237 7769Europe, Middle East, Africa: +44 1440 714 850Asia Pacific: +852 3160 9800 • Latin America: +52 55 5081 1650 2011-10-20-vertx-br-en
