EDGE EVO Solo ESHR40 L网络控制器/读取器和模块

Single-Door Access Control System IP INTELLIGENCE AT THE DOOR WITH INTEGRATEDICLASS® READER FOR STAND-ALONE APPLICATIONS Features: ƒEmbedded User Interface — no externalsoftware requirement.ƒRemotely managed using standard webbrowser.ƒConnect to any Wiegand or Hi-O reader.Supports up to 2 readers (purchase ofadditional add-on boards may be required).ƒWeb Browser Security — uses SSL3.0 (Secure Socket Layer) and TLS3.1(Transport Layer Security) to establish asecure web browser connection.ƒNetwork Configuration — Works withinDHCP or Static IP networks for plug andplay installation.ƒMulti Language Support — Supports thefollowing languages: English, French,German, Spanish (International), Russian,Portuguese (Brazilian), Italian, Chinese(Simplified), Japanese, Korean, Dutch andTurkish.ƒAll-in-One UI Page – “Door Dashboard”accesses door commands, status, alarms,and recent events from all screens.ƒBack-up and restore of data from user PC.ƒUser upgradable firmware.ƒManages Card only, PIN only, Card and PINtransactions.ƒManages up to 1000 cardholders/credentials.ƒManages 8 schedules and 3 intervals eachday.ƒView last 5000 events.ƒStandardized report generation, includingCSV export.ƒFirst Person In (Snow day) and PINsuppression schedulesƒBuilt-in 802.3af Power over Ethernet (PoE),with 9.6 W available for readers, externalfield devices and locking hardware.ƒWet or dry door relays, including 12 or 24VDC wet relay lock support.ƒInterface to Hi-O door hardware and Hi-Ocompliant readers provides streamlinedand smart installation. ƒCost-Effective –Uses Power over Ethernet (PoE) to power reader and door strike.Eliminates the need for separate power supplies for many situations.ƒRemote Management –Managed over the network through a standard web browser.No software installation necessary.ƒIntegrated iCLASS Reader –The included reader/controller reads iCLASS cards andopens the door; access a single-lock output using an IO module designed to mountbehind reader in US single-gang box or in hollow door frame.ƒScalable –Can be remotely reconfigured through the web browser from stand-aloneoperation to a system controller in a host environment of multiple controllers. HID Global’s EDGE EVO® Solo ESHR40-LController/Reader and Module is a cost-effective, stand-alone, single-door IP -enabledaccess control solution that distributesintelligence right to the door. EDGE EVO Soloprovides the ability to power all devices arounda door using Power over Ethernet (PoE),significantly reducing total door installationcosts by removing the need to install a separatepower supply. It also utilizes less expensiveCAT5 wiring compared to traditional structuredcable. The easy-to-use user interface enablesa number of simple access controllermanagement features. The solution also enableselectronic access control for sites with one ortwo doors and a card population of 10’s or 100’sof cards. The integrated controller and reader offersinteroperability with iCLASS® credentials. Thecontroller/reader is mounted indoors on aUS single-gang or EU/APAC 60mm roundelectrical box next to the door. The controller/reader is connected to an IO interface moduleinstalled either behind the reader in a USsingle-gang electrical box or within a hollowdoor frame using a four-wire bus. The lockoutput terminates at the IO interface module,eliminating the need to wire to secure location(ceiling). Because the user interfaces to the controllerutilizes a standard web browser, there is noneed to install software on a PC. After thecontroller is plugged into the local area network(LAN), it obtains its IPv4 address using DHCPor Static addressing. The user simply typesthe IP address into the web browser, whichinitiates a secure connection with the stand-alone panel. The All-in-One Door Dashboardprovides a simple user interface where the siteadministrator can add user information, modifyaccess rights, pull history reports, monitor dooractivity and provide general administration ofthe controller. Built on HID Global’s OPIN® developmentplatform, EDGE EVO Solo can be remotelyreconfigured through the web browser fromstand-alone operation to a system controller in ahost environment of multiple controllers. hidglobal.com Easily interfaced: Mounting options: Inputs for: ƒRJ-45 connector for Ethernet TCP/IP(10/100 Mbps).ƒQuick-disconnect screw terminalconnectors.ƒSoftware updates easily provided throughbrowser interface.ƒEasily upgrades to a hosted softwaresolution through the network interface. Controller/Reader is indoor rated only. Mountindoors on:ƒUS Single/Double-gang style electrical box.ƒEU/APAC 60mm round style electrical box.Lock Module designed to fit within US Single-gang box or hollow door frame.Wet output for:ƒ1 door strike. ƒProvides no discrete input interface.ƒProvides Hi-O interface to Hi-O compliantinput devices. Access control readers: Up to 2 Total Readers.ƒ1 Integrated Reader already included.ƒ1 Additional Hi-O iCLASS Reader.* SPECIFICATIONS NOTES: Combined pow
