EDGE EVO EH400高网络控制器

iCLASS Reader SINGLE DOOR NETWORKED ACCESS CONTROLLERFEATURING POWER OVER ETHERNET ƒOpen Architecture– Development platform enables use of hardware with anyOPIN compliant access control software from a wide variety of partnersƒHigh Performance– Powerful platform performance increases door uptime.ƒPower Over Ethernet (PoE)– Reduces wiring costs by powering controller,reader and door lock over one CAT-5 wire.ƒHigh Security– Increased security with encrypted data exchange around andbetween controller and all Hi-O enabled door components. Mountable on EU 60mm and US single-gang electrical boxes, the EH400 isroughly the size of an R40 iCLASS reader. HID Global’s Networked Access Solutionsprovide an open architecture developmentplatform that enables HID’s softwarepartners to deploy a wide variety ofversatile access control systems thatprotect their customers’ hardwareinvestments. ƒ300ft (100m), CAT-5ƒALPHA 9504C, ALPHA 9405F The EH400 has an optical tamper andinterfaces to Hi-O compliant devices,including Hi-O readers, Hi-O REX, Hi-OStrike and Hi-O Interface modules. Hi-O CANbus: ƒ100ft (30m) total bus lengthƒ30ft (10m) length between dropsƒ22AWG, 0.65mm, 0.33mm2 As part of HID Global’s Networked AccessSolutions family, the EDGE EVO® EH400is a single-door access control panel thatenables cost effective installation and highperformance access control functionality. EDGE EVO solutions provide access to acomplete ecosystem of partner solutionsto enable customizable products thatleverage the unique power of individualsoftware provider offerings. The EH400 makes local door decisions andcan interface with one or two Hi-O iCLASSreaders. Solutions are created for both on-sitesystem administration as well as serviceoriented off-site solutions, depending onthe OEM software provider’s total solution. hidglobal.com Hi-O door components with separatelypurchased Hi-O Interface Module.)ƒConnects to the host and other deviceson a TCP/IP network.ƒReceives and processes real-timecommands from the host softwareapplication, while reporting allactivity to host.Buffers up to 99,999transactions.ƒConnects directly to a Hi-O iCLASSreader(s) to support 1 or 2 readers. Features: cardholders.ƒProvides encrypted door bus usingHi-O technology so that controllerand Hi-O enabled readers and doorcomponents communicate securely.ƒConnects to the host and other deviceson a TCP/IP network.ƒProvides access control processing,host interface and power for a singledoor, including a separate HI-O iCLASSreader, Hi-O lock and Hi-O request-to-exit device.(Compatible with non- ƒProvides a complete and fullyfunctional hardware/firmwareinfrastructure for IP access controlsoftware host systems.ƒSupports Power Over Ethernet(PoE), enabling cost-effectiveinstallation utilizing existing networkinfrastructure.ƒStores a complete access control andconfiguration database for one doorwith one or two readers and 125,000 SPECIFICATIONS An ASSA ABLOY Group brand © 2012 HID Global Corporation. All rights reserved.HID, the HID logo, EDGE, EDGE EVO, and iCLASSare trademarks or registered trademarks of HIDGlobal in the U.S. and/or other countries. All othertrademarks, service marks, and product or servicenames are trademarks or registered trademarks oftheir respective owners.2012-04-23-edge-evo-eh400-reader-ds-en North America: +1 949 732 2000Toll Free: 1 800 237 7769Europe, Middle East, Africa: +44 1440 714 850Asia Pacific: +852 3160 9800Latin America: +52 (55) 5081-1650 hidglobal.com
