EDGE EVO Solo ESH400网络控制器

IP INTELLIGENCE AT THE DOOR INCORPORATING ANYREADER FOR STAND-ALONE APPLICATIONS Features: ƒEmbedded User Interface — no externalsoftware requirement.ƒRemotely managed using standard webbrowser.ƒConnect to any Wiegand or Hi-O reader.Supports up to 2 readers (purchase ofadditional add-on boards may be required).ƒWeb Browser Security — uses SSL 3.0(Secure Socket Layer) and TLS 3.1(TransportLayer Security) to establish a secure webbrowser connection.ƒNetwork Configuration — Works withinDHCP or Static IP networks for plug andplay installation.ƒMulti Language Support— Supportsthe following languages: English, French,German, Spanish (International), Russian,Portuguese (Brazilian), Italian, Chinese(Simplified), Japanese, Korean, Dutch andTurkish.ƒAll-in-One UI Page — “Door Dashboard”accesses door commands, status, alarms,and recent events from all screens.ƒBack-up and restore of data from user PC.ƒUser upgradable firmware.ƒManages Card only, PIN only, Card and PINtransactions.ƒManages up to 1000 cardholders/credentials.ƒManages 8 schedules and 3 intervals eachday.ƒView last 5000 events.ƒStandardized report generation, includingCSV exportƒFirst Person In (Snow day) and PINsuppression schedules.ƒBuilt-in 802.3af Power over Ethernet (PoE),with 9.6 W available for readers, externalfield devices and locking hardware.ƒWet or dry door relays, including 12 or 24VDC wet relay lock support.ƒInterface to Hi-O door hardware and Hi-Ocompliant readers provides streamlined andsmart installation. ƒCost-Effective– Uses Power over Ethernet (PoE) to power reader and doorstrike. Eliminates the need for separate power supplies for many situations.ƒRemote Management– Managed over the network through a standard webbrowser. No software installation necessary.ƒTrue Flexibility– Attach any Wiegand access control reader; use Hi-OiCLASS readers for added security.ƒScalable– Can be remotely reconfigured through the web browser fromstand-alone operation to a system controller in a host environment ofmultiple controllers. HID Global’s EDGE EVO® Solo ESH400-KController is a cost-effective, stand-alone,single-door IP -enabled access control solutionthat distributes intelligence right to the door.EDGE EVO Solo provides the ability to powerall devices around a door using Power overEthernet (PoE), significantly reducing total doorinstallation costs by removing the need to installa separate power supply. It also utilizes lessexpensive CAT5 wiring compared to traditionalstructured cable. The easy-to-use user interface enables a numberof simple access controller managementfeatures. The solution also enables electronicaccess control for sites with one or two doorsand a card population of 10’s or 100’s of cards. The flexible ESH400-K Controller offers a widerange of card to reader interoperability. With aseparately connected reader, the ESH400-K isa perfect solution for migrating existing readerinstallations to the “edge” of the network. Thecontroller connects to any Wiegand reader,providing the flexibility to choose card/readertechnology such as iCLASS SE or to use existingcard and reader populations already on site. Because the user interfaces to the controllerutilizes a standard web browser, there is no needto install software on a PC. After the controlleris plugged into the local area network (LAN), itobtains its IPv4 address using DHCP or Staticaddressing. The user simply types the IP addressinto the web browser, which initiates a secureconnection with the stand-alone panel. TheAll-in-One Door Dashboard provides a simpleuser interface where the site administrator canadd user information, modify access rights, pullhistory reports, monitor door activity and providegeneral administration of the controller. Built on HID Global’s OPIN® developmentplatform, EDGE EVO Solo can be remotelyreconfigured through the web browser fromstand-alone operation to a system controller in ahost environment of multiple controllers. hidglobal.com Mounting Options: Always mount in environmentally protectedand secure area. ƒUS Single/Double-gang style electricalbox.ƒEU/APAC 60mm round style electricalbox.ƒReverse Mount Accessory available forflush mount in cabinet. Non-latching wet/dry relay outputs for: ƒ1 door strike.ƒ1 auxiliary device: door held/forcedalarm, alarm shunt, host offline(communications down), or generalpurpose. Inputs for: ƒDoor monitor switch.**ƒRequest-to-Exit switch.**ƒAC Fail Monitor.ƒBattery Fail Monitor.ƒEnclosure Tamper. Access control readers: ƒUp to 2 Wiegand or Hi-O iCLASSReaders.** Easily Interfaced: ƒRJ-45 connector for Ethernet TCP/IP(10/100 Mbps).ƒQuick-disconnect screw terminalconnectors.ƒSoftware updates easily providedthrough browser interface.ƒEasily upgrades to a hosted softwaresolution through the network interface. *Can be configured as a general purpose input ** 2 Readers can be supported as follows (a) 2 xHi-O iCLASS readers, (b) 1 x Wiegand and 1 x Hi-OiCLASS reader or (c) 2 x Wiegand readers (requiresseparate pu
