EDGE EVOEHR40和EHRP40Hi-O控制器/读卡器
SINGLE DOOR NETWORKED ACCESS CONTROLLER/ CONTACTLESS ICLASS READER AND INTERFACEMODULE Open Architecture– Development platform enables use of hardware with anyOPIN compliant access control software; pick from a wide variety of partners.Integrated Reader– Integrated controller / reader provides 13.56 MHz iCLASSsmart card compatibility and controller logic in one device.Power Over Ethernet (PoE)– Reduces wiring costs by powering controller /reader and module and door components using one CAT-5 wire.High Security– Increased security with encrypted data exchange around the doorand between controller and Hi-O devices, including readers, locks and request toexist devices. Hi-O compliant devices, including Hi-Oreaders, Hi-O REX, Hi-O Strike and Hi-OInterface modules. The integrated readeroffers interface to 13.56 MHz compliantcredentials, including iCLASS. Additionally,the EHRP40 model reads 125 kHzcompliant credentials, including HID Prox,Indala Prox, EM4102 and AWID. HID Global’s Networked Access Solutionsprovide an open architecture developmentplatform that enables HID’s softwarepartners to deploy a wide variety ofversatile access control systems thatprotect their customers’ hardwareinvestments. Cable Specifications Ethernet: 300ft (100m), CAT-5ALPHA 9504C, ALPHA9405F Hi-O CANbus: 100ft (30m) total bus length30ft (10m) length betweendrops22AWG, 0.65mm, 0.33mm2 As part of HID Global’s Networked AccessSolutions family, the EDGE EVO® EHR40 &EHRP40 Controller/Reader is a combined,single-door access control panel andreader with native Highly IntelligentOpening (Hi-O) interface that enablescost effective installation, secure readerand door component connection and highperformance access control functionality. EDGE EVO provides access to a completeecosystem of software provider solutionsto enable customizable solutions thatleverage the unique power of individualsoftware provider software. Solutions are created for both on-sitesystem administration as well as serviceoriented off-site solutions, depending onthe OEM software provider’s total solution. The EHRP40 is installed at the door,has an optical tamper and interfaces to hidglobal.com Features: Provide access control processing, hostinterface and power for a single door,including an integrated iCLASS reader,Hi-O lock and Hi-O request-to-exitdevice.(Compatible with non-Hi-O doorcomponents with separately purchasedHi-O Interface Module.) Integrated reader processes 13.56 MHziCLASS credentials, ISO14443A CSNs.EHRP40 model additionally reads 125 kHzcredentials, including HID Prox, Indala,AWID and EM4102.Connects to the host and other devices on aTCP/IP network.Provides encrypted door bus using Hi-Otechnology so that controller and Hi-Oenabled readers and door componentscommunicate securely. Provides a complete and fully functionalhardware/firmware infrastructure for IPaccess control software host systems.Supports Power Over Ethernet (PoE),enabling cost-effective installationutilizing existing network infrastructure.Stores a complete access control andconfiguration database for one doorwith one or two readers and 125,000cardholders. Receives and processes real-timecommands from the host softwareapplication, while reporting all activity tohost.Buffers up to 99,999 transactions. SPECIFICATIONS An ASSA ABLOY Group brand © 2012 HID Global Corporation. All rights reserved.HID, the HID logo, EDGE, EDGE EVO, and iCLASSare trademarks or registered trademarks of HIDGlobal in the U.S. and/or other countries. All othertrademarks, service marks, and product or servicenames are trademarks or registered trademarks oftheir respective owners.2012-04-23-edge-evo-ehr40-ehrp40-rdrs-ds-en North America: +1 949 732 2000Toll Free: 1 800 237 7769Europe, Middle East, Africa: +44 1440 714 850Asia Pacific: +852 3160 9800Latin America: +52 (55) 5081-1650 hidglobal.com
