ThinLine II读卡器

LOW PROFILE PROXIMITY CARD READER Providing performance and reliability, HID’s attractive, unobtrusive ThinLine® IIproximity card reader is housed in a two-piece, weatherproof secure pottedenclosure. ƒEasily installed and maintained with the use of replaceable covers.ƒAvailable with a Wiegand or Clock-and-Data interface.ƒProvides high reliability, consistent read range and low power consumption.ƒFeatures include multicolor LED and internal control or host control of theLED and beeper.ƒMounts directly on metal with minimal impact on the read range performance.ƒAesthetic design available in two cover designs and four colors to match any décor.ƒIncludes multilingual installation manual. hidglobal.com FEATURES polycarbonate enclosure designed to withstand harsh environments,providing reliable performance and a high degree of vandalresistance. ƒSecurity– Recognizes card formats up to 85 bits, with over 137billion unique codes.ƒAudiovisual Indication–A red LED flashes green and the beepersounds when reader is presented with a proximity card. Themulticolor LED and beeper can also be controlled individually bythe host system.ƒDiagnostics– On reader power-up, an internal self-test routinechecks and verifies the setup configuration, determines theinternal or external control of the LED and beeper, and initializesreader operation. An additional external loop-back test allows forthe reader outputs and inputs to be verified without the use ofadditional test equipment.ƒIndoor/outdoor Design– Sealed in a rugged, weatherized ƒEasily Interfaced- Wiegand output model interfaces with all existingWiegand protocol access control systems. Clock-and-Data (magneticstripe) model interfaces with most systems that accept magneticstripe readers. ƒOptions–LED and beeper operation SPECIFICATIONS hidglobal.com North America: +1 512 776 9000Toll Free: 1 800 237 7769Europe, Middle East, Africa: +44 1440 714 850Asia Pacific: +852 3160 9800Latin America: +52 55 5081 1650
