R90远程读卡器

Long Range Contactless Smart Card Reader • Read Only • 6150 Features: HID’s iCLASS® Long Range Reader is idealfor installations incorporating parkingcontrol and long read range applications.The iCLASS Long Range Reader packagesall the electronics in one rugged, attractive,and easy-to-install housing. Experience enhanced versatility: ƒLong read range distance(up to 18 inches or 45 centimeters)ƒReads all HID iCLASS® andISO15693 compatible (CSN)credentialsƒ“Parking Hold” feature allowsconnection to a loop detectorto ensure accurate detection ofvehicles in parking lanes ƒAuto tuning for more consistent readranges.ƒUse one reader to read standardproximity format data from HID iCLASScredentials.ƒMulticolor LED and beeper can becontrolled internally or at host.ƒTwo R90 units can operate one meterapart for “HI-LO” truck and car instal-lations.ƒWiegand output easily interfaces withmost existing Wiegand protocol accesscontrol panels. Using the 13.56 MHz technology platform,the iCLASS R90 read-only contactlesssmart card long range reader combinesthe longer read range of proximity with theflexibility and heightened security of smartcard technology, making it ideal for accesscontrol applications. iCLASS smart readers and cards makeaccess control more powerful, moreversatile, and most importantly, offerenhanced security through encryption andmutual authentication. At the same time,iCLASS is user-friendly, delivering the sameconvenience and reliability of HID’s world-renowned Prox technology. HID’s offeringsencompass the industry’s broadest rangeof open standard contactless smart cardproducts, available from over 40,000resellers worldwide. Appreciate advanced security: ƒAll RF data transmission between thecard and reader is encrypted using asecure algorithm.ƒBy using industry-standard encryptiontechniques and advanced keymanagement systems, iCLASS reducesthe risk of compromised data orduplicated cards.ƒOpen architecture design permits theflexibility to use standard or customkeys for enhanced security. Featuring crisp architectural styling, thereader has an elegantly curved faceplate.The high intensity LED provides clear,visual feedback even in direct sunlight.Distinct tone sequences indicate statusconditions. hidglobal.com SECURITY EASILY INTERFACED 64-bit authentication keys are extremely secure. Readers and cardsrequire matching keys to function. All RF data transmission betweenthe card and reader is encrypted, using a secure algorithm.The keymanagement system reduces the risk of compromised data or dupli-cated cards. The reader’s Wiegand output easily interfaces with most existing Wie-gand protocol access control panels. The reader reads standard proxim-ity format data from HID iCLASS cards and will output data as encoded. AUDIOVISUAL INDICATION Audio transducer provides various tone sequences to signify accessgranted, access denied, power up, and diagnostics. Visually impairedcardholders can easily distinguish between access granted and accessdenied. The R90 includes a tamper switch to provide electronic notification ofreader tampering. PROGRAMMING/CONFIGURATIONKey management is made easy! All cards are shipped with unique diver- sified keys, and readers are shipped with compatible keys. All keys arederived from the HID Standard transport key. While cards and readerswith Standard keys are interchangeable, the keys are highly secure, andcards can be made unique by ordering with iCLASS® Elite formatting. When an iCLASS card is presented to the reader, the red LED flashesgreen and the beeper sounds.The multicolor LED and beeper canalso be controlled individually by the host system. INDOOR/OUTDOOR DESIGNRugged, weatherized polycarbonate enclosure, designed to withstand harsh environments, provides reliable performance and resistance tovandalism. DIAGNOSTICS On reader power-up, an internal self-test routine checks and verifiesthe setup configuration, determines the internal or external control ofthe LED and beeper, and initializes the reader’s operation. SPECIFICATIONS Learn about HID Global’s green initiativeshidglobal.com/green North America: +1 949 732 2000Toll Free: 1 800 237 7769Europe, Middle East, Africa: +49 6123 791 0Asia Pacific: +852 3160 9800Latin America: +52 55 5081 1650 An ASSA ABLOY Group brand © 2013 HID Global Corporation/ASSA ABLOY AB. All rights reserved. HID, HID Global, the HID Blue Brick logo, the Chain Design and iCLASSare trademarks or registered trademarks of HID Global or its licensor(s)/supplier(s) in the US and other countries and may not be used withoutpermission. All other trademarks, service marks, and product or service names are trademarks or registered trademarks of their respective owners. 2014-01-28-pacs-iclass-r90-ds-en hidglobal.com
