电动汽车减速器产品实拍及原理图

电动汽车减速器产品实拍及原理图 1吉凯恩GKN 3株齿 4德纳DANA Dana-e-Gearbox Supplying 139 kW (189 horsepower) of continuouspower and DANA Electrical Vehicle Gearbox DANA Electrical Vehicle Gearbox 5格特拉克Getrag GETRAG 2eDCT600-transmission •Manufacturer: GETRAG •Gear reduction: 8.75:1 •Axle at Transmission: 33 Spline, •Input Shaft: 17 Spline, 0.75 Inch •Weight: 75lbs 6伊顿Eaton •2speed range section as in current successful product•Planetary transmission•Pneumatic gear activation system•Aluminum housings•Baulk ring synchronizer•Forced lubrication (oil pump)•Main gear set above oil level for increased efficiency Specifications Eaton2-Speed Transmission SpeedsL–Low, H–High, N–NeutralGear position sensor: L–low, H–high, N–neutralMax input torque 700 NmMax. Input speed 6000 rpmWeight：81 kg (without Oil)Oil Capacity：4.6 liters (with transmission installed in vehicle at9.75°(input end up)Gear RatiosLow-3.529:1 7邦奇PUNCH 1. Two integrated planetary gear sets 2. Single stage final drive3. Controlled dry friction brake4. Selectable dog clutch5. Differential gear
