iCLASS阅读器

13.56 MHZ CONTACTLESS SMART CARD READERS.PLUG-N-PLAY WITH NEW AND EXISTING ACCESSCONTROL SYSTEMS ƒSimple Upgrades–iCLASS® readers have the same wiring connections, same low-current consumption and same 5 to 12 volt operation as our Prox readersƒMultiple Applications–HID Connect offers over 70 technology partners which haveembedded iCLASS technology into their products providing a single card solutionfor all your application requirementsƒGSA approved–Included in the U.S. General Services Administration (GSA) FIPS 201Approved Products ListƒField Upgradeable–Utilize firmware upgrade cards to modify reader firmware whileinstalled on site iCLASS® 13.56 MHz contactless smart cardsand readers make access control morepowerful, more versatile and offer enhancedsecurity through data encryption and mutualauthentication between the card and reader. Prox format and user identificationnumbers are brought across to youriCLASS credentials, including HIDCorporate 1000 formats. Also, Elitecustom key program is available for ahigher level of security. iCLASS readers are user-friendly, deliveringthe same convenience and reliability ofHID’s world-renowned Prox technology, withstate-of-the-art features, driven by evolvingindustry requirements. ƒSecure -All RF data transmissionbetween the card and reader isencrypted using a secure algorithm.By using industry-standard encryptiontechniques and advanced keymanagement systems, iCLASS reducesthe risk of compromised data orduplicated cards. Upgrading from Prox to iCLASS technologyhas never been so simple. All iCLASS readersprovide the same wiring connections,low-current consumption and 5 to 16 voltoperation as our Prox readers. Additionally,you can transfer your Prox format and useridentification numbers to iCLASS credentials,making the change completely transparent toyour access control system. ƒInteroperability -iCLASS is based onISO interoperability standards providingcompatibility with many popular cardtechnologies (ISO 15693, ISO 14443Aand ISO 14443B). ƒOptimal Read Range Performance -An auto-tuning feature automaticallyadjusts the reader for optimal read rangeperformance on any mounting surface. Key Features ƒFormat Portability -Upgrading iscompletely transparent since the same hidglobal.com SPECIFICATIONS FEATURES: ƒSecurity -64-bit authenticationkeys are extremely secure. Readersand cards require matching keys tofunction. All RF data transmissionbetween the card and reader isencrypted using a secure algorithm.The key management system reducesthe risk of compromised data orduplicated cards. ƒElite Custom Keys -Customkeys provide the highest level ofsecurity, where cards and readersare uniquely matched to individualsites or customers, and are non-interchangeable. Combining Elitecustom keys with our Corporate1000 can offer companies a scalablesolution that can be implemented infacilities worldwide. ƒAudiovisual Indication -Audiosounder provides various tonesequences to signify accessgranted, access denied, power upand diagnostics. Visually impairedcardholders can easily distinguishbetween access granted and accessdenied. A high-intensity light barprovides a clear visual status indicationin red, green or amber, even in brightsunlight.Note:Light bar will illuminateamber when a FIPS 201/PIV card isread. ƒIndoor/Outdoor Design -Rugged,weatherized polycarbonate enclosure,designed to withstandharshenvironments, provides reliableperformance and resistance tovandalism. ƒEasily Interfaced -The reader’sWiegand output easily interfaces withmost existing Wiegand and Clock-and-Data protocol access control panels.The reader reads standard proximityformat data from HID iCLASS® cardsand will output data as encoded.When reading ISO 14443A cards(MIFARE®/ DESFire®), the reader canbe configured to output 26-bit, 32-bit(MSB), 32-bit (LSB), 34-bit, 40-bit or56-bit Wiegand formats based on theCSN (card serial number). ƒOptions -Colors - Black or GrayKey Management - Standard or EliteSelectable Output Type (for MIFAREcards)Termination Options - 18" Pigtail orTerminal StripProgrammable LED/Beeper operationAccessory - Security Tool; 04-0001-03Transit – Enable FeliCa IDm and/orCEPAS CAN/CSN An ASSA ABLOY Group brand © 2012 HID Global Corporation. All rights reserved. HID, the HID logo, iCLASS SE, and iCLASS are trademarks or registered trademarks ofHID Global in the U.S. and/or other countries. All other trademarks, service marks, and product or service names are trademarks or registeredtrademarks of their respective owners.20110319-pacs-iclass-r-series-c-readers-ds-en hidglobal.com
