iCLASS CP400编程器

CONTACTLESS SMART CARD PROGRAMMER• 3150 The iCLASS® CP400 Card Programmeris designed for on-site programming ofaccess control data, Personal IdentificationNumber (PIN) codes, and user data ontoHID iCLASS cards. It allows HID proximityformats, keypad PIN codes and user datafields to be programmed directly intoiCLASS contactless smart cards. Thisenables the system manager to stock blankcards and program cards on demand whennew cardholders are added to the system.To ensure security of the format and cards,an iCLASS Card Programmer license isrequired. Additional Capabilities ƒStores PIN codes on the card for usewith the iCLASS RK40 and RWK400keypad readers configured for local PINverification.ƒPrograms four, 16-character user datafields on the card, that can later be readon the programmer.ƒCreates site-specific, high-securityauthentication keys that areprogrammed into both readers andcards.ƒCreates reader configuration cardsto program new authentication keysinto readers and change other readeroperating parameters.ƒReads any iCLASS card when theauthentication key is pre-stored in theprogrammer.ƒPrints card numbers directly onto thecards using a PVC card printer or onstandard Avery labels.ƒMaintains a secure, encrypted databaseon a personal computer.ƒPersonalized for individual customers(proprietary formats are restricted toauthorized users). The iCLASS CP400 Card Programmeralso allows the end user to upgrade theirsystem to the highest security level bycreating unique, site specific authenticationkeys preventing cards from any otherlocation or source from being recognizedby the system including 26-bit Wiegandformat. The iCLASS CP400 Card Programmerincludes a desktop reader/writer, CD-ROMwith programming software and documen-tation, personalization diskette, universalpower supply, and serial cable. hidglobal.com ƒPrint Cards or Label Stock-Create Card Number Prefix / Position Card Number on card /Select label size (1" x 2-5/8" or 1/2" x 1-3/4”)ƒPrint Cross Reference Report for a ProfileƒAdd New User(Inactive, Operator, Administrator)ƒConfiguration Card Manager (create keys and reader configuration cards) CAPABILITIES: ƒCreate New Card Profile (template for batch programming) -Create Profile Name / Select Format / Select Security Mode- Standard or High / Select PIN-on-Card type - None, User/Defined, Random, Sequential (w/ start #) / Enter Site Code,Starting ID Number / Enter Quantity to be programmed ƒProgram a Card Profile READER/WRITER: -Select Profile Name / For each card you may enter: PIN (if user-defined), Password, User Data Fields 1-4 (16 characters) ƒThe iCLASS reader/writer provides audiovisual feedback with aspeaker and light bar. A desktop stand with shelf holds the card,key or tag while programming. A DB9S serial connector and DCpower jack are located on the rear of the stand. ƒProgram User Fields (for a previously programmed card)ƒProgram Skipped Cards (for a profile where some cards failed toprogram)ƒRead Cards (previously programmed if key is known) POWER SUPPLY: ƒA universal power supply is provided with United States plug.For international use, just replace the removable power cord andadd a local adapter. SPECIFICATIONS hidglobal.com América do Norte: +1 512 776 9000Ligação Gratuita: 1 800 237 7769Europa, Oriente Médio, África: +44 1440 714 850Ásia Pacífico: +852 3160 9800América Latina: +52 55 5081 1650
