CASI接口适配器

Connects HID readers to CASI Access Control Systems • 4033 Features: Allows HID readers to be economically installed on a CASI-RUSCO® system. Using oneinterface module per reader, up to sixteen HID proximity, Wiegand, magnetic stripe, oriCLASS® readers may be connected to two CASI-RUSCO 8RP Interface Boards in anyMicro/5® Control Panel. ƒMonitors Door Position andRequest to Exit inputs.ƒCompact unit mounts in standarddual-gang J-Box with coverplate.ƒSupports the following formats: The HID 4033 Adapter Module duplicates special functions provided by CASI-RUSCOsystems, such as Request to Exit (REX), Door Monitor inputs, Door Strike output, andreader presence supervision. • HID 37-Bit• Standard 26-Bit• Casi-Rusco BCD Format• Casi-Rusco 3201 Format• HID Corporate 1000 Format ƒSupports Reader Statussupervision feature in new HIDproximity readers. ƒThe HID 4033 Interface Adapterfor CASIsystems convertsWiegand card data intoCASI-RUSCO F2F data. SPECIFICATIONS Specifications subject to change without notice. (Please see “How to Order” guide for adescription of the options and associated part numbers). Learn about HID Global’s green initiativeshidglobal.com/green North America: +1 949 732 2000Toll Free: 1 800 237 7769Europe, Middle East, Africa: +49 6123 791 0Asia Pacific: +852 3160 9800Latin America: +52 55 5081 1650 An ASSA ABLOY Group brand © 2013 HID Global Corporation/ASSA ABLOY AB. All rights reserved. HID, HID Global, the HID Blue Brick logo, the Chain Design and Prox aretrademarks or registered trademarks of HID Global or its licensor(s)/supplier(s) in the US and other countries and may not be used withoutpermission. All other trademarks, service marks, and product or service names are trademarks or registered trademarks of their respectiveowners. hidglobal.com 2013-12-18-pacs-prox-casi-interface-ds-en
