中国光储直柔工程应用案例

案例调研 SurveysofChina’s PEDFBuildingEngineering Application 深圳市建筑科学研究院股份有限公司2023年10月31日Shenzhen Institute of Building Research Co., Ltd 关于作者 康靖深圳市建筑科学研究院股份有限公司高级技术经理李婉溢深圳市建筑科学研究院股份有限公司助理主任 ABOUT THE AUTHORS Kang JingShenzhen Institute of Building Research Co., LtdLi WanyiShenzhen Institute of Building Research Co., Ltd 致谢 本研究由深圳市建筑科学研究院股份有限公司统筹撰写，由能源基金会提供资金支持（课题编号：G-2206-33942）。 ACKNOWLEDGEMENT Thisreport is a product of Shenzhen Institute of BuildingResearch Co., Ltdand is funded by Energy Foundation China(GrantNumber:G-2206-33942). 免责声明 -若无特别声明，报告中陈述的观点仅代表作者个人意见，不代表能源基金会的观点。能源基金会不保证本报告中信息及数据的准确性，不对任何人使用本报告引起的后果承担责任。 -凡提及某些公司、产品及服务时，并不意味着它们已为能源基金会所认可或推荐，或优于未提及的其他类似公司、产品及服务。 Disclaimer -Unless otherwise specified, the views expressed in this report arethose of the authors and do not necessarily represent the views of EnergyFoundationChina.Energy Foundation China does not guarantee theaccuracy of the information and data included in this report and will not beresponsible for any liabilitiesresultingfrom or related to using this reportby any third party.-The mention of specific companies, products and services does not imply that they are endorsed or recommended by Energy FoundationChina in preference to others of a similar nature that are not mentioned. 摘要 双碳目标下，建立新型电力系统是中国深化能源结构改革的重大战略方针。为了实现以上战略目标，国家与地方政府相继颁布了多项提高可再生能源发电占比、强化光伏产业及用户侧应用的相关规定，而如何应对分布式可再生能源快速发展和高比例接入是电力系统需要应对的挑战。光储直柔建筑是以直流配电为基础，集成可再生能源发电以及分布式储能的新型建筑。在以太阳能光伏和储能电池为主的分布式电源以及电动汽车大比例接入建筑的趋势背景下，直流配电系统可通过减少交直流变换环节降低能量损失，以实现可再生能源本地消纳的形式减少电网供电压力。因此，光储直柔建筑能有效提升系统能量使用和管控效率，并提高建筑微电网的供电安全性与可靠性。该应用可作为一种以净零能耗为目标的全新适宜技术，实现建筑节能和减排，以及城市可持续发展的长远战略目标。 近年来在全国各地政府的支持下，更多的光储直柔建筑项目开始投建并逐步进入运行阶段，为这项初生的技术注入了强劲的活力。中国光储直柔工程应用案例调研报告采用分析结合案例调研的方法，旨在多方面的介绍这一工程技术在中国的应用基础，发展现状，内在驱动力和技术障碍，以及未来发展方向。报告正文共四个章节，章节一对相关政策基础和工程标准现状做了总结。章节二描述了目前的六十余项光储直柔项目的调研结果，分析应用特征与技术现状，并对技术特点与不足进行了总结与评价。针对工程利益主体所关心内容进行分析，总结出了技术发展的优势和劣势，更重要的是根据述求归纳政策引导方向，这部分内容体现在章节三中。章节四为本报告结论，讨论了中国光储直柔工程应用特点以及引导该技术发展的政策方向。该报告不仅是对中国光储直柔建筑技术应用的阶段性总结，同时也是对该领域不同工程技术的调研与适用性分析，结论可为意向建设光储直柔项目的同行提供参考。 Executive Summary In response to the carbon peaking and carbon neutrality goals, itis a critical strategic guideline for deepening the reform of energystructure in China and set up a new power system. To achieve theabove strategic goal, the State and local governments have issuedmultiple regulations to increase the proportion of renewable energygeneration, further develop PV industry, and strengthen user-sideapplication. However, the power system still faces challenges in theapproach to addressing the rapid development and high-proportionaccess to distributed renewable energy. As a newmodeofenergyapplication,PEDFbuildingsare based on DC distribution system whileintegratingrenewable energy generation and distributed energystorage. It has become a trend that the distributed generation withsolar PV and battery energy storage (BES) as the mainstays, andelectric vehiclesare accessing the buildings as new energy consumers.Asa result,DC distribution system can reduce energy loss bylessening the conversions from DC to AC, and thereby alleviates thepressure of renewable energy impacts to utility grid. Therefore,PEDFbuildingscan effectively improve the system energy usage andcontrol efficiency and provide more security and reliability for buildingmicrogrid energy consumption. The application ofPEDFbuildings canbe used as a brand-new appropriate technology to achieve the long-termstrategic targets of building energy conservation,emissionreduction, and urban sustainable development, with a goal of net-zero energy consumption.Withthe support of local governments in China,more PEDF buildingprojects have gradually been constructed and operatedrecently, injecting strong impetus for this emerging technology. Thispaper intends to make an introduction to this engineering technologyfrommultiple aspects such as its application basis,developmentstatus,internal driving strength,and technical barriers in China.Section1summarizes relevant policies and standards which supportdevelopment ofPEDFbuilding industries. The investigation results weconductedfor more than 60 PEDF projects and their applicationcharacteristics，technology status aresummarized and estimatedinsection2.Section 3 focuses on analyzing what concerns theengineeringstakeholders,summarizingthestrengthsandweaknessesof the technology during development,and moreimportantly, identifying the policy guiding directions according to theappealsfor this technology.Conclusions of this research arepresentedin Section 4.This report not only makes a periodicsummary of the application ofPEDFbuilding technology in China, butalsoinvestigates and analyzes the applicability of differenttechnologies in this field. The conclusions can be referred by buildingpractitionerswho intend to be engaged in PEDF projects asengineering experiences. 目录 1政策与标准现状.......................................................................................................................11.1政策环境............
